DESCRIPTION

Basic Info

Power Source	Electric
Automatic Grade	Automatic
Name	Vegetable Dehydrator Cassava Dryer Microwave
Core Components	PLC, Magnetron
Heating Method	Electric Heating
Function	Drying, Dewatering
Magnetron	Toshiba, Samsung, Panasonic
Capacity	Customized
Advantage	Fast Drying Speed
Microwave Power	About 2450 MHz
Energy	Electricity
Machine Material	Food Grade Stainless Steel
Transport Package	Plastic Film
Specification	customized
Trademark	Jinan FLD
Origin	China
HS Code	8438800000
Production Capacity	200pieces Per Year

Product Description

Vegetable Dehydrator Cassava Dryer Microwave Vacuum Oven Nut Food Drying Machine Spices Herbs Dryer1.Detailed Images:

Industrial Continuous Grain Nuts Microwave Drying Sterilizing Oven is a new type of drying equipment with high production efficiency and low operating cost. It is also an efficient and environmental friendly energy-saving equipment; especially for foods that contain bactericidal and fresh-keeping functions while drying. This equipment has been widely involved in the pharmaceutical, food, chemical, building materials and other industries.

Microwave Vacuum Oven Nut Food Drying Machine Spices Herbs Dryer Characteristics : 1, the energy conversion efficiency is high, the heating sped is fast. Microwave oven itself does not heat, but the microwave energy through the material, so that the material inside the polar molecules of mutual friction and heat. So there is no energy loss.
2, expansion effect is obvious. Microwave heating effect, so that the material inside the water molecules fast vaporization,to achieve the purpose of expanding.
3, low temperature sterilization, less loss of nutrients. Microwave sterilization was carried out under the double action of the heat effect and the non thermal effect of microwave. Compared with the conventional temperature sterilization, the sterilization effect could be satisfied.
4, easy to use. The microwave power and the transmission belt speed can be continuously adjusted, there is no thermal inertia, which can be opened or stopped, and is simple and easy to control.

Scope of application :Microwave drying equipment mainly used in Tenebrio molitor Tenebrio: microwave drying, drying, microwave drying and other insect larvae Vegetable Dehydrator Cassava Dryer Product Sample:

Product Parameters

Industrial Continuous Grain Nuts Microwave Drying Sterilizing Oven

No	Model	Power	Dehydration Capacity	Sterilization Capacity	Size(L*W*H)
1	WB12KWSP	12KW	12kg/h	120-150kg/h	7*0.84*1.75m
2	WB-20KWSP	20KW	20kg/h	192-240kg/h	9.4*0.84*1.75m
3	WB-30KWSP	30KW	30kg/h	300-375kg/h	11.7*0.84*1.75m
4	WB-40KWSP	40KW	40kg/h	396-495kg/h	10.52*1.06*1.75m
5	WB-50KWSP	50KW	50kg/h	504-630kg/h	11.7*1.06*1.75m
6	WB-60KWSP	60KW	60kg/h	600-750kg/h	12.86*1.06*1.75m
7	WB-70KWSP	70KW	70kg/h	696-870kg/h	14.03*1.06*1.75m
8	WB-80KWSP	80KW	80kg/h	804-1000kg/h	14.86*1.2*1.75m
9	WB-100KWSP	100KW	100kg/h	1000-1250kg/h	15.2*1.2*1.75m
10	WB-150KWSP	150KW	150kg/h	1500-1875kg/h	21.05*1.2*1.75m

4.WORKING VOLTAGE:When the equipment running, the microwave is first generated by the microwave generator, and the feeding device is input into the microwave heater; the material is sent to the microwave heating chamber by the transmission system, and the moisture in the material is heated and evaporated under the action of the microwave energy, and the water vapor passes. The dehumidification system is eliminated to achieve the purpose of drying. The bacteria in the material are killed by the biological and thermal effects produced by the microwave electromagnetic field. Since the microwave acts directly on the material, the drying temperature is low and the speed is fast, and the loss of the active ingredient in the material is small.

After Sales Service

1).Provide factory layout according to your factory size in advance;2).Provide the basic formula;3).Inspect the machine before leaving the factory;Oversea installation and commissioning equipment;4).Technician will work with your workers together and teach your workers how to install machines, how to operate machines, how to maintain machines during daily working;5).Our engineers will teach your workers how to clean the extruder, how to change the screw, how to change barrel etc, and provide technology support with you forever;6).Provide English Version of Installation / Operation / Service / Maintenance Manual.

Our Advantages

1 With the function drying, heating, cooking, sterilization, unfreezing, dehydration, inactivation etc. 2 PLC auto or button control system, support data saving, outputting, and printing3 Microwave power stepless adjustable, temperature and humidity chain intelligent control4 Speed can be adjusted.5 The machine size can be adjusted according to users' workshop area.6 Fast continuous production, which is uniform and thorough.7 The perfect mechanical and electrical integration design, the real-time monitoring of multiple sensors, safe and reliable.8 Adopt food-grade materials.9 Production can be monitored, quantified and controlled.

Company Profile

Jinan FLD Machinery Co; Ltd. is a professional supplier of food processing machines. Our company's Motto is: "Technology Makes Easy". We offer to cooperate with our customers for mutual and beneficial development. All Inquiries are welcome.We are located in Jinan, the Capital of Shandong Province. Jinan FLD Machinery Co; Ltd is vested with many staffs with many years of experience in supplying the food processing machines.Our main products line include food extrusion machine, soya meal/meat processing machines, industrial micro wave oven, packaging machines, rice cake machine etc... Most importantly, we also provide formulas, technology supports, machine inspection service, etc^..Cooperating with different manufacturers and research centers, we provide the food processing machines with outstanding quality. We have a group of experienced experts and outstanding engineers who do provide the professional service delivery and installation. Based on the clients specific requirement, we also design and produce the machines to order. We have through the years established good working relationship with some reputable organizations both at home and abroad with outstanding goodwill.Whatever food processing machine you need from China, contact: Jinan FLD Machinery Co; Ltd. A one stop shop in the middle of China.

FAQ

Q: How long is your delivery time?

A: Generally speaking, it is 7 days if the machines are in stock. Or it is 25 days if the goods are out of stock.

Q: Could you supply all the parameters about the Industrial Continuous Grain Nuts Microwave Drying Sterilizing Oven ?

A: Of couse. We are delighted to supply all the informtion that you want to know.

Q: How about the after sale service?

A: We will send our engineers to your factory for installation and training.

Q: How should I know the process of manufacturing if we pay the down payment?

A: We will supply you an exact delivery time as soon as we received your deposit. During the manufacturing, we will make reports for you to let you know the process.
