DESCRIPTION

Basic Info

Product Description

TM-IR-B801100

Ambient temperature

~200°C

Radiation + convection

tunnel oven

8443192290 415v 3phase 50hz

Stainless steel 304 lining

11 m * 1m * 1.3m

Inlet 2m Outlet 1m

4 zones ,2m per heat zones.

2+2+2+2+2+1=11

370W*4PCS Top fans (0.5Hp)

4 Axial fans via 1pcs VDF regulates speed

Black antistatic PTFE (Teflon) cloth belt no hole

belt width: 0.8 m

Belt thickness 0.4mm

Work temperature: 100 or 200 Celsius

Medium wave infrared carbon fiber heat tube on the top 36 pcs

36*1kw+4*0.37kw+other=38kw

All lamp 418v

4 cylinder Lift open oven cover

4 'Exit'=Exhaust gas or smoke exhaust (With control Valve)

Free fitting

Spare 0.8m width 0.4mm thickness Black antistatic PTFE belt-----1 pcs

Spare Carbon fiber lamp---10pcs

Spare TM-UV400L Transformer---1 pcs

Cabinet oven 8419899090 418v 3phase 50hz

Shape Size (L*W*H) mm 1640*0.95*2200

Weight 500kg

Inner size of box: (L*W*H) 1000*660*1500mm

Power (Kw) 12

Heat pipe 418v

Range of Temperature(ºC) 20-200

Stainless steel 304 lining

SUS304

Drying Rack

Trolley

7326909000 Shelf dimensions 900 * 600 * 1450

Mesh size 800 * 500(fit 2pcs 3045 film)

50 layers*25mm layer spacing

no grid,

Material stainless steel 304

4 inch wheels

Temperature resistance 250 Celsius /60min

Tamprinter only focuses on one thing: how to make your label and sticker screen printing work choose a better set of equipment solutions.

Company Profile

SHENZHEN TAMPRINTER PRINTING MACHINERY CO.,LTD. is a wholly-owned subsidiary of the Tamprinter printing machinery group limited designed to take up the invenstment ,design and construction of the most professional plastic sheet and paper screen printing machinery for world. We have supplied OEM service for the domestic counterparts since 2003. OEM products have been achieved CE certification.

Tamprinter printing machinery group limited (referred to as: Tamprinter brand printer supplier) is one of the first settled Made-In-China labels & stickers screen printing machinery foreign trade service market cross-border electricity providers.Tamprinter are Alibaba and Made-In-China,Diytrade Gold service provider, has service throughout the printing industry of more than 85 country. The main business is providing one-stop solution, mainly offer Screen Printing Complete Equipment for service for the manufacturer of technical labels, stickers, labels. such as Aluminium labels printing ,Aluminium ceiling auto screen print, stainless labels printing, polycarbonate labels screen printing, brass signs screen printing, PVC signs embossing,3M self-adhesive stickers printing market. . . Etc.

In March 2013 the company strategic upgrades, invested Three millions to build a new printer factory , the depth of integration of B2B, the rich resources, the establishment of professional project team operates its own brand - TAMPRINTER, development of screen printing machinery products, to sheet screen printing equipments as an opportunity to develop more new business models and the extension of explosive force. We always adhere to the user first value and service concept, and strive to become the most word-of-mouth electricity supplier, and strive for service millions of labels and stickers manufacturer .

Original intention(bodhicitta-samutpada):

People oriented management in enterprise, Good business is business for responsibility, People share prosperity and responsibility together!

Key products:

Screen printing machine,UV curing machine, IR tunnel dryer.
